| 1 | Product number | P3.91 | ||
| 2 | Pixel pitch | 3.91mm | ||
| 3 | Pixel density | 65536 points/㎡ | ||
| 4 | Pixel composition | One pure red tube, one pure green tube, one pure blue tube | ||
| 5 | Display thickness | 3mm | ||
| 6 | LED light tube | SMD1717 gold wire? | ||
| 7 | Driver IC | Light driver in one (customized) | ||
| 8 | Module size | Length 1000*Width 125mm | ||
| 9 | Cabinet size | Length 1000*Width 500mm | ||
| 10 | Power consumption | Average: 300W/㎡, maximum: 800W/㎡ | ||
| 11 | Screen weight | Less than 5kg/㎡ | ||
| 12 | power supply | Yuanchi 400W (with PFC) | ||
| 13 | Connector | Copper material | ||
| 14 | Wire and Cable | National standard multi-core wire, certified | ||
| 15 | PCB board | International A material | ||
| 16 | Screen transparency | 90% | ||
| 17 | Protection level | IP30 | ||
| 18 | Flatness | Seam between modules <0.1mm | ||
| 19 | average life span | More than 100,000 usage hours | ||
| 20 | out of control point | Less than one ten thousandth (when used continuously) | ||
| 21 | Power supply requirements | 220V±10%; AC50HZ, three-phase five-wire | ||
| 22 | continuous working time | greater than 72 hours | ||
| 23 | Warranty | 1 year | ||
| 24 | screen brightness | 1000-2500cd/m2 | ||
| 25 | Visible distance | 4m～100m | ||
| 26 | Light emitting components | Dehe | ||
| 27 | Dimming | Automatic adjustment and manual adjustment according to ambient brightness, greater than or equal to 256 levels | ||
| 28 | perspective | 140 horizontally, 140 vertically | ||
| 29 | Grayscale | 65536 levels of grayscale | ||
| 30 | White point color temperature | 5500K-9300K | ||
| 31 | Image adjustment | White balance, contrast, vision, tone adjustment | ||
| 32 | Image Processing | Images are processed with noise reduction, enhancement, motion compensation, and color coordinate transformation | ||
| 33 | Drive mode | Constant current drive | ||
| 34 | scanning method | static | ||
| 35 | Leakage current to earth | Less than 2mA | ||
| 36 | Signal processing capabilities | ＞10bit | ||
| 37 | Brightness uniformity | When the entire screen is the brightest monochrome, the minimum pixel brightness/maximum pixel brightness is greater than 0.95 | ||
| 38 | decay rate | Less than 0.05% for 2 years | ||
| 39 | Contrast | 5000：1 | ||
| 40 | Refresh frequency | 3840HZ | ||
| 41 | frame change frequency | ＞60HZ | ||
| 42 | video input | Compatible with PAL\NTSC TV signals, compatible with HDTV | ||
| 43 | Software interface | WINDOWS7、NT、XP、2000 | ||
| 44 | display mode | 32-bit true color 1024X768 | ||
| 45 | mean time between failures | ＞10000小時(shí) | ||
| 46 | Lamp bead defective pixel rate | ＜ 1/1000, and distributed discretely | ||
| 47 | Control System | Colorite, Mosier, Nova synchronous/asynchronous | ||
| 48 | Use a ring mirror | “◆Working environment: -10～+65 ℃/ 10～90 %RH ◆Storage environment: -40～+85 ℃/ 10～90 %RH” |
||
| 49 | Certification | 3C、CE、FCC | ||
| 50 | Installation method | Paste?? | ||
| 1 | Product number | P6.25 | ||
| 2 | Pixel pitch | 6.25mm | ||
| 3 | Pixel density | 25600 points/㎡ | ||
| 4 | Pixel composition | One pure red tube, one pure green tube, one pure blue tube | ||
| 5 | Display thickness | 3mm | ||
| 6 | LED light tube | SMD1717 gold wire? | ||
| 7 | Driver IC | Light driver in one (customized) | ||
| 8 | Module size | Length1200mm*Width250mm | ||
| 9 | Cabinet size | Lenght1200mm*Width500mm | ||
| 10 | Power consumption | Average: 180W/㎡, maximum: 600W/㎡ | ||
| 11 | Screen weight | Less than 5kg/㎡ | ||
| 12 | power supply | Yuanchi 400W (with PFC) | ||
| 13 | Connector | Copper material | ||
| 14 | Wire and Cable | National standard multi-core wire, certified | ||
| 15 | PCB board | International A material | ||
| 16 | Screen transparency | 90% | ||
| 17 | Protection level | IP30 | ||
| 18 | Flatness | Seam between modules <0.1mm | ||
| 19 | average life span | More than 100,000 usage hours | ||
| 20 | out of control point | Less than one ten thousandth (when used continuously) | ||
| 21 | Power supply requirements | 220V±10%; AC50HZ, three-phase five-wire | ||
| 22 | continuous working time | greater than 72 hours | ||
| 23 | Warranty | 1 year | ||
| 24 | screen brightness | 1000-2000cd/m2 | ||
| 25 | Visible distance | 6m～100m | ||
| 26 | Light emitting components | Dehe | ||
| 27 | Dimming | Automatic adjustment and manual adjustment according to ambient brightness, greater than or equal to 256 levels | ||
| 28 | perspective | 140 horizontally, 140 vertically | ||
| 29 | Grayscale | 65536 levels of grayscale | ||
| 30 | White point color temperature | 5500K-9300K | ||
| 31 | Image adjustment | White balance, contrast, vision, tone adjustment | ||
| 32 | Image Processing | Images are processed with noise reduction, enhancement, motion compensation, and color coordinate transformation | ||
| 33 | Drive mode | Constant current drive | ||
| 34 | scanning method | static | ||
| 35 | Leakage current to earth | Less than 2mA | ||
| 36 | Signal processing capabilities | ＞10bit | ||
| 37 | Brightness uniformity | When the entire screen is the brightest monochrome, the minimum pixel brightness/maximum pixel brightness is greater than 0.95 | ||
| 38 | decay rate | Less than 0.05% for 2 years | ||
| 39 | Contrast | 5000：1 | ||
| 40 | Refresh frequency | 3840HZ | ||
| 41 | frame change frequency | ＞60HZ | ||
| 42 | video input | Compatible with PAL\NTSC TV signals, compatible with HDTV | ||
| 43 | Software interface | WINDOWS7、NT、XP、2000 | ||
| 44 | display mode | 32-bit true color 1024X768 | ||
| 45 | mean time between failures | ＞10000小時(shí) | ||
| 46 | Lamp bead defective pixel rate | ＜ 1/1000, and distributed discretely | ||
| 47 | Control System | Colorite, Mosier, Nova synchronous/asynchronous | ||
| 48 | Use a ring mirror | “◆Working environment: -10～+65 ℃/ 10～90 %RH ◆Storage environment: -40～+85 ℃/ 10～90 %RH” |
||
| 49 | Certification | 3C、CE、FCC | ||
| 50 | Installation method | Paste installation | ||
